Grill model: 9877-87 Sovereign 90

0

67487 Broil King 58" Select grill cover 67487. Broil King Select Series covers are crafted from durable and weather resistant PVC / 500 x 300 denier polyester lining. These durable covers feature:

• Hook-and-loop tabs that secure the cover around the grill
• Polyester handles for easy removal
• Hanging loops for convenient storage
• The Broil King brand logo on the front MORE...

0

68487 Broil King 58" premium grill cover 68487. Broil King premium covers are crafted of durable water resistant PVC with heavy woven 900D polyester backing.

Exact fit for models:

• Baron 440, 490 Series grills
• Crown 10, 90 Series grills, post model
• Signet 70, 90 Series grills
• Sovereign 20, 40, 70, and 90 Series grills MORE...

3

10081-BK630 NAMEPLATE HI BROIL KING BLACK ZINC
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10081-BK630 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10081-BK603

MORE...

5

10571-6 Genuine OEM Heat indicator. About 2 3/8" wide and 2" high. The threaded stem is about 5 /16" diameter and 1 1/8" long.

Note: Part 10571-6 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:31935-5
• OMC:571-C500

MORE...

7

S21233 Hinge pin clip.

Note: Part S21233 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:S21232

MORE...

9

10225-T536 Genuine OEM cast iron cooking grid, SOLD INDIVIDUALLY.

• Sold individually.
• Number required varies.
• Porcelain enameled cast iron, flat matte finish. MORE...

10

10222-E400 Genuine OEM stainless steel Flav-R-Wave.

Note: Part 10222-E400 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10222-E405

MORE...

11

10225-E451 Genuine OEM warming rack MORE...

12

10222-E401 Genuine OEM stainless steel divider. MORE...

15

10390-E20 Genuine OEM stainless steel Dual-Tube burner. Use air shutter to control flow of air for LP gas, less air, and for natural gas, more air. NOTE: Manufacturer changed back mounting to a 90 degree bend.

Note: Part 10390-E20 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10390-E20D
• OMC:10390-E20E
• OMC:10390-E20LP
• OMC:10390-E20M
• OMC:10390-E20ME
• OMC:10390-E20NG
• OMC:10390-E20NGE

MORE...

17

10342-246 Genuine OEM electronic push-button 3-spade igniter.

• Uses AAA battery (not included)
• .Requires 3/4" mounting hole

Note: Part 10342-246 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10342-C246

MORE...

18

10342-E12 Genuine OEM electrode with 11" connector wire that has a flat/spade female end; use with AA or AAA battery powered ignitors.
Temporarily out of stock. Orders for this part will ship late May. MORE...

19

10342-E400A Genuine OEM collector box, complete. Replaces parts 10342-E400 and 10342-E401, which have been discontinued as separate parts.

Note: Part 10342-E400A is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10342-E400
• OMC:10342-E401

MORE...

21

10444-E579 CONTROL ASSY 52BTU 5V NG *
SPECIAL ORDER PART. This part is not in stock. Orders for this part may not ship for 4 to 10 weeks, depending on availablity and ship times from the manufacturer. MORE...

21A

Y-11230 Cotter pin MORE...

21B

10110-45 Gas tube to rear burner assembly. Connects control valve assembly to rear rotisserie burner. 450/600.
SPECIAL ORDER PART. This part is not in stock. Orders for this part may not ship for 4 to 10 weeks, depending on availablity and ship times from the manufacturer. MORE...

22

ASCPL-1 Five piece 3/8" natural gas quick disconnect set includes:

• Part ASCPL-2 12ft vinyl 3/8" ID Sturgis hose (3/8" inside diameter outside diameter about 1/2") with solid brass fittings
• Part ASCPL-3 Sturgis brand 3/8" quick connect brass coupler
• Hansen & Sturgis dust cover
• plastic dust plug
• Plastic 3/8 MPT Snap Tite
• Suitable up to approximately 60,000 BTU. MORE...

23

22001-768 Genuine OEM large control knob.

• Off position D-Value: 6 o'clock
• Knob diameter: 2 1/4"
• Socket diameter: 5/16"
• Knob shaft: 1/2" MORE...

23A

10472-E38 CONTROL KNOB - BEZEL BLK MORE...

25

10222-E402-R Replacement for stainless steele baffle. Fits Signet/Sovereign.

Note: Part 10222-E402-R is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10222-E402

MORE...

47

10184-E691 ALIGNMENT, BRACKET BLACK MORE...

52

10184-E78A Genuine OEM End Cap, door. Left hand side, with magnet.
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10184-E78A is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10184-E78

MORE...

53

10184-E76 END CAP DOOR BOTTOM LEFT A MORE...

54

10184-E79A Genuine OEM End Cap, door. RIght hand side, with magnet.

Note: Part 10184-E79A is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10184-E79

MORE...

55

10184-E77 END CAP DOOR BOTTOM RIGHT A MORE...

56

10892-7G Genuine OEM 7" cart wheel with 3/8" axel hole. Mini hub cap is # 00400251, sold separately.

Note: Part 10892-7G is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10892-07
• OMC:10892-17
• OMC:10892-7
• OMC:10892-70

MORE...

60

10711-E47 END CAP SIDE SHELF RHS MORE...

68

S21362 REAR BURNER SPRING MORE...

76

S21255 Washer MORE...

78

10892-15 Genuine OEM caster wheel; approximately 2 3/8" diameter.
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10892-15 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10892-13

MORE...

104

Y-12835 SCREW-PHCP 6-32X1/4 TY-F JS500 MORE...

108

PB20-60 S/B LID HANDLE WAGON ENCLOSER* MORE...

110

10225-T10 Genuine OEM side burner grid MORE...

111

10390-E10 Genuine OEM Side Burner. Use air shutter to adjust for LP (less air flow) or natural gas (more air flow).
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10390-E10 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10390-E10D
• OMC:10390-E10E

MORE...

113

10342-T16 Genuine OEM 28" wire for side burner. One female spade connector, one female round connector..

Note: Part 10342-T16 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:342-C5364

MORE...

114

10393-K40 Genuine OEM Cover, side burner. MORE...

123

S15115 Genuine OEM disposable grease pans. Package of 10. Each measures 4.75"x6"x1". MORE...

136

10184-E33 ROTISSERIE SHIELD BRACKET FOR RIGHT SIDE WITH TWO MOUNTING HOLES. (Also, a replacement for 10184-E43.)

Note: Part 10184-E33 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10184-E43

MORE...

137

10184-E42 ROTISSERIE MOTOR BRACKET. MORE...

138

10184-E44 ROTISSERIE SHIELD BRACKET FOR LEFT SIDE WITH ONE MOUTNING HOLE. MORE...

?

66123-UNI Premium universal cooking grid. Porcelain treated cast iron. Matte finish. Sold individually. See part 66123-UNI-X3 for a set of three (3) grids. MORE...

?

66124-1PC Cast iron cooking grid. Porcelain treated, matte finish. Sold individually, number required varies.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

CG-74P-CI Cast iron cooking grid. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

CG-74P-CI-X3 Cast iron cooking grids. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8" x 8 1/4"
• Overall dimensions: 16 7/8 x 23 3/4" MORE...

?

CG-74P-CI-X3 Cast iron cooking grids. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8" x 8 1/4"
• Overall dimensions: 16 7/8 x 23 3/4" MORE...
