Grill model: 960-44 Regal XL40

3

10081-BK630 NAMEPLATE HI BROIL KING BLACK ZINC
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10081-BK630 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10081-BK603

MORE...

5

10571-6 Genuine OEM Heat indicator. About 2 3/8" wide and 2" high. The threaded stem is about 5 /16" diameter and 1 1/8" long.

Note: Part 10571-6 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:31935-5
• OMC:571-C500

MORE...

7

S21233 Hinge pin clip.

Note: Part S21233 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:S21232

MORE...

9

10225-T536 Genuine OEM cast iron cooking grid, SOLD INDIVIDUALLY.

• Sold individually.
• Number required varies.
• Porcelain enameled cast iron, flat matte finish. MORE...

10

10222-T425 Genuine OEM stainless steel Flav-R-Wave heat plate. Also replaces porcelain-steel lava rock/briquette grate part# 10222-T424, which has been discontinued by the manufacturer.

Note: Part 10222-T425 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10222-T424

MORE...

11

10225-T528 Genuine OEM warming rack MORE...

15

10390-T501 Genuine OEM stainless steel Infinity burner assembly. This burner assembly does not include the electrodes. Includes:

• One stainless steel Infinity burner
• Twin venturi with spider exclusion screens

Note: Part 10390-T501 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10390-T501D
• OMC:10390-T501S

MORE...

17

UP-8B Universal 3 outlet rotary spark generator. Includes knob.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

17

10472-K40 Genuine OEM rotary igniter knob. MORE...

18

10342-T301 Genuine OEM collector box and electrode assembly. Includes:

• burner mounted box with mounting screw
• ceramic electrode and 17" wire with round connector and protective sleeve
• Use with burners 10390-T401 (14102) and 10390-T501 (14212) MORE...

21

10442-R82 CONTROL ASSEMBLY 52 10M 3V LP
SPECIAL ORDER PART. This part is not in stock. Orders for this part may not ship for 4 to 10 weeks, depending on availablity and ship times from the manufacturer. MORE...

21

10442-R83 CONTROL ASSEMBLY 52 10M 3V NG
SPECIAL ORDER PART. This part is not in stock. Orders for this part may not ship for 4 to 10 weeks, depending on availablity and ship times from the manufacturer. MORE...

21A

S13467-091 LP side burner hose no longer available separately. For safety reasons, now sold only as entire valve assembly. Please verify your model number per the certification tag located on your gas grill. You can contact the manufacturer directly or email us for more information. MORE...

21A

S13467-132 NG side burner hose no longer available separately.
Now sold only as entire valve assembly. Please verify your model number per the certification tag on your gas grill. MORE...

21A

Y-11230 Cotter pin MORE...

22

80012 24" LP hose and regulator with QCC-1 connection.

• For use on "new style" QCC-1 tanks.
• Consists of hose part# 01000 and regulator part# 00920.
• Hose end with SAE 3/8" female flare fitting connects to grill. MORE...

?

HR-4B Type 1 LP Regulator with 22" Pressure Hose and 3/8" Female Flare Fitting.FITS: Up to 60,000 BTUs MORE...

22

ASCPL-1 Five piece 3/8" natural gas quick disconnect set includes:

• Part ASCPL-2 12ft vinyl 3/8" ID Sturgis hose (3/8" inside diameter outside diameter about 1/2") with solid brass fittings
• Part ASCPL-3 Sturgis brand 3/8" quick connect brass coupler
• Hansen & Sturgis dust cover
• plastic dust plug
• Plastic 3/8 MPT Snap Tite
• Suitable up to approximately 60,000 BTU. MORE...

23

10472-K431 Control knob large. Black with stainless steel BA strip. MORE...

37

10184-R581 Shelf support, left. MORE...

38

10184-R591 SHELF SUPPORT RH BLK(18") MORE...

43

10958-R861 PEDESTAL SIDE PANEL 2004 BLACK -- 23 13/16 x 12.419 MORE...

47

10184-R19 TANK RETAINER-PEDESTAL-NEW MORE...

56

10892-8NG Genuine OEM 8" cart wheel with a 3/8" axel hole. Also replaces part# 10892-8, and 10892-8N which have been discontinued. Is a solid rubber wheel with a plastic hub, and it has a grey sidewall stripe instead of the white found on 10892-8N.

Note: Part 10892-8NG is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10892-8
• OMC:10892-8N
• OMC:SP17-22SC

MORE...

73

S21420 Push nut 3/8 MORE...

74

Y-6616 Bolt hex head 1 1/2" length MORE...

76

10239-7 Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Note: Part 10239-7 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10239-6

MORE...

78

10892-15 Genuine OEM caster wheel; approximately 2 3/8" diameter.
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10892-15 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10892-13

MORE...

104

Y-12835 SCREW-PHCP 6-32X1/4 TY-F JS500 MORE...

108

PB20-60 S/B LID HANDLE WAGON ENCLOSER* MORE...

110

10225-T10 Genuine OEM side burner grid MORE...

111

10390-E10 Genuine OEM Side Burner. Use air shutter to adjust for LP (less air flow) or natural gas (more air flow).
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10390-E10 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10390-E10D
• OMC:10390-E10E

MORE...

113

10342-T14 Genuine OEM 21" wire for side burner or other applications. One female spade connector, one female round connector. MORE...

114

10393-K40 Genuine OEM Cover, side burner. MORE...

123

S15115 Genuine OEM disposable grease pans. Package of 10. Each measures 4.75"x6"x1". MORE...

?

66123-UNI Premium universal cooking grid. Porcelain treated cast iron. Matte finish. Sold individually. See part 66123-UNI-X3 for a set of three (3) grids. MORE...

?

66124-1PC Cast iron cooking grid. Porcelain treated, matte finish. Sold individually, number required varies.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

CG-74P-CI Cast iron cooking grid. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

CG-74P-CI-X3 Cast iron cooking grids. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8" x 8 1/4"
• Overall dimensions: 16 7/8 x 23 3/4" MORE...

?

CG-74P-CI-X3 Cast iron cooking grids. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8" x 8 1/4"
• Overall dimensions: 16 7/8 x 23 3/4" MORE...
