Grill model: 960-24 Regal XL20

3

10081-BK630 NAMEPLATE HI BROIL KING BLACK ZINC
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10081-BK630 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10081-BK603

MORE...

5

10571-6 Genuine OEM Heat indicator. About 2 3/8" wide and 2" high. The threaded stem is about 5 /16" diameter and 1 1/8" long.

Note: Part 10571-6 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:31935-5
• OMC:571-C500

MORE...

7

S21233 Hinge pin clip.

Note: Part S21233 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:S21232

MORE...

9

10225-T536 Genuine OEM cast iron cooking grid, SOLD INDIVIDUALLY.

• Sold individually.
• Number required varies.
• Porcelain enameled cast iron, flat matte finish. MORE...

10

10222-T425 Genuine OEM stainless steel Flav-R-Wave heat plate. Also replaces porcelain-steel lava rock/briquette grate part# 10222-T424, which has been discontinued by the manufacturer.

Note: Part 10222-T425 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10222-T424

MORE...

11

10225-T528 Genuine OEM warming rack MORE...

15

10390-T501 Genuine OEM stainless steel Infinity burner assembly. This burner assembly does not include the electrodes. Includes:

• One stainless steel Infinity burner
• Twin venturi with spider exclusion screens

Note: Part 10390-T501 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10390-T501D
• OMC:10390-T501S

MORE...

17

10342-245 Genuine OEM electronic push-button 2-spade igniter.

• Uses AAA battery (not included)
• .Requires 3/4" mounting hole
• Also replaces part# 10342-242 and 10342-249

Note: Part 10342-245 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10342-242

MORE...

17

10472-K40 Genuine OEM rotary igniter knob. MORE...

18

10342-T301 Genuine OEM collector box and electrode assembly. Includes:

• burner mounted box with mounting screw
• ceramic electrode and 17" wire with round connector and protective sleeve
• Use with burners 10390-T401 (14102) and 10390-T501 (14212) MORE...

22

80012 24" LP hose and regulator with QCC-1 connection.

• For use on "new style" QCC-1 tanks.
• Consists of hose part# 01000 and regulator part# 00920.
• Hose end with SAE 3/8" female flare fitting connects to grill. MORE...

?

HR-4B Type 1 LP Regulator with 22" Pressure Hose and 3/8" Female Flare Fitting.FITS: Up to 60,000 BTUs MORE...

22

ASCPL-1 Five piece 3/8" natural gas quick disconnect set includes:

• Part ASCPL-2 12ft vinyl 3/8" ID Sturgis hose (3/8" inside diameter outside diameter about 1/2") with solid brass fittings
• Part ASCPL-3 Sturgis brand 3/8" quick connect brass coupler
• Hansen & Sturgis dust cover
• plastic dust plug
• Plastic 3/8 MPT Snap Tite
• Suitable up to approximately 60,000 BTU. MORE...

23

10472-K431 Control knob large. Black with stainless steel BA strip. MORE...

37

10184-R581 Shelf support, left. MORE...

43

10958-R861 PEDESTAL SIDE PANEL 2004 BLACK -- 23 13/16 x 12.419 MORE...

47

10184-R19 TANK RETAINER-PEDESTAL-NEW MORE...

51

10711-R562 Genuine OEM Side shelf, left side. MORE...

56

10892-8NG Genuine OEM 8" cart wheel with a 3/8" axel hole. Also replaces part# 10892-8, and 10892-8N which have been discontinued. Is a solid rubber wheel with a plastic hub, and it has a grey sidewall stripe instead of the white found on 10892-8N.

Note: Part 10892-8NG is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10892-8
• OMC:10892-8N
• OMC:SP17-22SC

MORE...

73

S21420 Push nut 3/8 MORE...

74

Y-6616 Bolt hex head 1 1/2" length MORE...

76

10239-7 Triangular handle washer. 1/8 in thick. Made of heat resistant compressed material.

Note: Part 10239-7 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10239-6

MORE...

78

10892-15 Genuine OEM caster wheel; approximately 2 3/8" diameter.
Temporarily out of stock. Orders for this part will ship late May.

Note: Part 10892-15 is the factory authorized replacement for the following parts, which are no longer available:

• OMC:10892-13

MORE...

123

S15115 Genuine OEM disposable grease pans. Package of 10. Each measures 4.75"x6"x1". MORE...

?

66123-UNI Premium universal cooking grid. Porcelain treated cast iron. Matte finish. Sold individually. See part 66123-UNI-X3 for a set of three (3) grids. MORE...

?

66124-1PC Cast iron cooking grid. Porcelain treated, matte finish. Sold individually, number required varies.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

CG-74P-CI Cast iron cooking grid. Porcelain treated, matte finish. FIts Kenmore And Other Import Grills. Sold individually, number required varies.
NOTE: This is an Aftermarket part, NOT an original factory part. MORE...

?

CG-74P-CI-X3 Cast iron cooking grids. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8" x 8 1/4"
• Overall dimensions: 16 7/8 x 23 3/4" MORE...

?

CG-74P-CI-X3 Cast iron cooking grids. SET OF THREE (3) panels.

• Porcelain treated, matte finish
• Each panel measures 16 7/8" x 8 1/4"
• Overall dimensions: 16 7/8 x 23 3/4" MORE...
